Gas forge H1




Model: Gas forge H1

The Gas Forge H1 by Nargesa is a propane furnace designed for the efficient and safe heating of irons for artistic forging. The furnace is equipped with a burner to heat the iron and work it: molding, bending, piercing, welding, tempering, forging, shoeing horses, etc. It can be used to manufacture a variety of items, such as horseshoes, knives, swords, axes, sculptures, garden furniture, chairs, and tables.

Efficiency, safety, and environmental friendliness are the three main features of the H1 furnace. It consumes up to 75% less gas than other furnaces in its category, while reaching a temperature of over 1300°C. It has new safety systems to protect the operator, fulfilling the regulation RD919/2006 and certified by the General Laboratory of Tests and Investigations: APPLUS Technology Center. The furnace is also respectful to the environment, with emissions below 0.002% of CO and an internal vermiculite coating that is 100% natural and recyclable.

Gallery

H1 Metalworking Machinery with Langbow

Technical Features

The H1 propane furnace has a variety of technical features that make it advantageous for forging.

Safety:

  • The H2 forging furnace has all the necessary safety devices for the well-being of the operator that will handle it.
  • The furnace meets the regulations in force in Spain, the Regulation of appliances that use gas as fuel RD919 / 2006.

Automatic Electronic Ignition:

  • Prevents the operator from inserting their hands in the combustion chamber to turn on the gas.
  • No tool is necessary to generate the spark.

Gas System Integrated in the Furnace Structure:

  • The components are entirely protected from impacts that could cause leaks.

Insulation of the Combustion Chamber:

  • These elements are made of a 100% natural material, compacted vermiculite, which is not harmful to health.
  • 100% recyclable as it does not include glass fibers or ceramics.

Anti-Return Valve:

  • This valve regulates the direction of the gas flow preventing it from being addressed to the cylinder.

Thermocouple Safety Valve:

  • This device closes the passage of the gas when the combustion chamber cools due to an anomaly, avoiding any possible leak.

Energy Efficiency:

  • The furnace’s R&D department takes into account the topic of saving energy for the furnace.

Fuel Consumption:

  • The consumption of Nargesa furnaces has been reduced by 75%, which means it consumes 1/4 of the fuel used by the same furnaces in its category.
  • With a LPG propane gas cylinder of 35Kg, the H2 Furnace will operate 50 hours with its two burners at full operation. If we only use one burner, then performance will double.

Gas Losses:

  • There is no fuel waste as all the propane gas that enters the combustion chamber burns without any sort of waste.
  • This process is possible due to the new burners designed and manufactured by Nargesa.

Respect for the Environment:

  • The insulating material of the combustion chamber, the compacted vermiculite, is a 100% recyclable material and does not generate waste.
  • Emissions emitted by the furnace are 0.002%, certified by the General Laboratory of Tests and Investigations: APPLUS Technology Center.

Technical Characteristics

The technical characteristics of the H1 propane furnace are as follows:

  • One burner
  • Automatic electronic ignition
  • Gas hose made of stainless steel
  • Precision pressure regulator with built-in pressure gauge
  • Integrated bar support
  • Adjustable pressure

The Nargesa H1 forging furnace is an effective appliance due to its simplicity, dimensions, easy ignition, and fast reach of the optimum working temperature. It complies with the current regulations in Spain, specifically the Regulation of appliances that use gas as fuel RD919/2006. The Forge furnaces H2 and H3 also meet these regulations.
